GENERAL SPECIFICATIONS - Max. Working panel height with straight edge 60 mm - Applicable banding material in coils: thin edge and PVC up to 3 mm D2xk3nnf SYSTEM AND OPTIONALS OF THE PANEL HANDLING - Running driving chain - Top pression unit made by motorized rubbered belt - Top pression unit with adjustable height in automatic by numerical control - Adjusting in continuos feeding speed with regulation in automatic by numerical control 18 - 25 m/min - Input panel guide - Lateral bar with lines. Heavy duty industrial edgebander with 'Airforce' zero glue line and electronic setting of working groups; Premilling, NC setting / Gluepot (eva & 'Airforce') / side pressure rollers, NC setting / end trim saws / Tilting trimmers, NC setting / Corner rounding, NC setting / Radius scrapers / Flat scrapers / Spindle moulder for grooving / Buffing mops. Panel height 10-60 mm Panel height with corner rounding unit Bam0cjxzpe (depending on profiles) 10-35/60 mm Height of edge-banding material 14-64 m. Edge banding machine Brandt Optimat KD 68 CF built 2002 workpiece width of min. 65 mm workpiece length of min 160 mm workpiece height of min. 8-40 mm edge thickness min max 0.4 8 mm feed m/min 11 m / min fixed hinged side right joining India - 2 engines Glue specifying glue roll gluing unit hot melt Adhesive edge magazine role 3 mm edge magazine strips Yes edge magazine solid 8 mm compression zone straight caps chamfer straight bevel/RADIUS milling profile milling/copying (2Motore) prof.
Holz Her 1442 Machine Manual
Bdcmxaxaeq Edge thickness: min. 0.4 mm - max. 5 mm, Worpiece thickness: min 8 mm - max. 55 mm, Workpiece length min 140 mm, Workpiece width: min. 80 mm, Feed speed 10.50 m/min, Gluing unit, Automatic edge magazine for 1 edge roller and strips, Pressure group with (1+2) rollers, Snipping unit: 2 tilting motors from 0° up to 15° power 0.35 kw-12000 rpm, Rough trimming unit: 2 x 0.55 kw-12000 rpm, Fine trimming unit: 2 x 0,35 kw-12000 rpm tilting motors from 0° up to 10°, Edge buffing unit GfZoPr.
